Fuel bowl thermostat

[RBernardi]

How the hell do you unhook the wire from the connector? I've pried on it with flat heads and it just chips away the plastic, so I stopped before I broke it.



[79jasper]

What do you mean? It's already unplugged.

Oh yeah *fuel heater*

Sent from my SAMSUNG-SM-G935A using Tapatalk



[RBernardi]

What do you mean? It's already unplugged.

Oh yeah *fuel heater*

Sent from my SAMSUNG-SM-G935A using Tapatalk

Sorry the pictures I'm using are for reference the plug I'm talking about is the middle one. Anyone have the answer? I just got the new one from dieselorings an hope to put it in tomorrow.



[79jasper]

Ah.
It's probably just old and brittle.
Really far as the heater is concerned, best to just leave it unplugged anyways.
Pry under the end with the wire.

Sent from my SAMSUNG-SM-G935A using Tapatalk



[RBernardi]

10-4 I figured it just unplugged, but I didn't want to get too aggressive as it was breaking on me already.



[79jasper]

Worst case scenario, you have to get a new pigtail for it.

Sent from my SAMSUNG-SM-G935A using Tapatalk



[gnxtc2]

Leave it unplugged, you don't need it. If the heater shorts out (very common), it'll leave you stranded.

I believe there is a nut on the inside of the fuel bowl. You need to remove the filter stand pipe with a 7/8 crowfoot wrench..... CAUTION: the stand pipe is left hand thread.

Top plug is fuel striction sensor
Middle plug is fuel heater
Bottom plug is water in fuel sensor
